HIACE H5C
Description
ENGINE |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model & Engine Model | KLQ6540 (RHD) 3TZ (Toytota Technology) |
||||||||||
| Emission | Euro III Technology source: Toyota |
||||||||||
| Fuel Type | Gasoline | ||||||||||
| Displacement | 2693 cc | ||||||||||
| Rated power (HP) | 163 | ||||||||||
| Max. Torque (Nm/rpm) | 260/2600-3600 | ||||||||||
TRANSMISSION |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | ZM025 5MT | ||||||||||
| No. of Gears | 5 Forward & 1 Reverse ) | ||||||||||
SUSPENSION |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front & Rear: | Front double wishbone independent suspension/ rear leaf dependent suspension | ||||||||||
| Driving mode | Front Engine Rear Drive | ||||||||||
STEERING & CLUTCH |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Steering | hydraulic power steering，Angle adjustable | ||||||||||
| Clutch type | Single piece dry diaphragm spring | ||||||||||
BRAKES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Front & Rear | Front disk rear drum | ||||||||||
| Parking Brakes | Mechanical | ||||||||||
WHEELS & TYRES |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Tyres: Radical – 195R15C
Wheels rim: Aluminium alloy wheel Rims *4 |
|||||||||||
CHASSIS :
DIMENSIONS |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheel Base(mm) | 3110 | ||||||||||
| Overall Length(mm) | 5380 | ||||||||||
| Overall Width(mm) | 1880 | ||||||||||
| Overall Height(mm) | 2285 | ||||||||||
| Curb Weight（kg） | 2285 | ||||||||||
| Turning Radius (m) | 6.3 | ||||||||||
| Ground Clearance(mm) | 180 | ||||||||||
CAPACITY |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Fuel Tank | 70 | ||||||||||
SEATING CAPACITY |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Seating Capacity | 12/15/16 seats | ||||||||||
